SECTION 10—FRONT RIGGINGS
At’m 44 Part No. 1125035
SECTION 10—FRONT RIGGINGS
WARNING
After any adjustments, repair or service and before use, make sure that all attaching
hardware is tightened securely - otherwise injury or damage may result.
While the wheelchair is moving, minimum ground clearance for the front rigging is
two inches. If the wheelchair is not moving, the front rigging MUST maintain a
minimum of one inch ground clearance - otherwise personal injury and damage may
result.
Before performing any maintenance, adjustment or service verify that On/Off
switch on the joystick is in the Off position.
Installing/Removing the Front Rigging Assembly
NOTE: For this procedure, refer to FIGURE 10.1.
Installing
1. Turn the front rigging assembly to the side (open footrest is perpendicular to the
wheelchair).
2. Insert the mounting pin on the front rigging assembly into the front rigging support
bracket.
3. Rotate the front rigging assembly towards the inside of the wheelchair until it locks
into place.
NOTE: The footplate will be facing the inside of the wheelchair when locked in place.
4. Repeat STEPS 1-3 for the other front rigging assembly.
5. If necessary, adjust the footrest height. Refer to Adjusting Footrest Height
on page 45.
Removing
1. Push the front rigging release lever inward while rotating the front rigging assembly
outward.
2. Lift the front rigging assembly out of the front rigging support bracket.
3. Repeat STEPS 1-2 for the other front rigging assembly, if necessary.
