SECTION 8—BATTERIES
Part No. 1125035 41 At’m
FIGURE 8.5 Charging Using an Independent Charger - Charger Plugged Directly to Batteries
Independent
Charger
Battery
Pack
Charger Jumper Cable
Plug into Wall Outlet
Female 3-Pin
Connector
3-Pin Charger
Connector
AC Power Cord
RED and
BLACK Battery
Connectors
