59
10.1.1.3 Removal/refitting of front wheel (3-wheel version)
Requirements:
• 2x open-ended spanners 17 mm
• Carefully tip the scooter onto one side.
• Remove the wheel locknuts (1) using both open-ended
spanners, then remove the wheel from the fork.
Reassembly
Reassembly takes place in reverse order. Make sure that the wheels are reassembled to give
the same direction of travel as previously.
