68
Driving characteristics
Speed
• 6 km/h
• 10 km/h
• 12 km/h
Min. braking distance
• 1000 mm (6 km/h)
• 2100 mm (10 km/h)
• 2900 mm (12 km/h)
Max. safe slope ******
• 3-wheel: 8° (14 %)
• 4-wheel: 12° (21 %)
Max. climbable obstacle height
• 80 mm
Turning diameter
• 3-wheel: 2250 mm
• 4-wheel: 2800 mm
Drive range in accordance with
ISO 7176-4:2008 ***
• 42 km
Dimensions
Overall length
• 3-wheel: 1270 mm
• 4-wheel: 1290 mm
Drive unit width
• 625 mm
Overall width (armrest adjustment
range)
• 630 ... 725 mm
Total height
• 1200 mm
Seat width
• 508 mm (20 inch)
Seat depth
• 470 mm (18,5 inch)
Seat height
• 420/445/470/495 mm
Backrest angle
• 95° ... 140°
Armrest height
• 210 ... 255 mm
