Invacare RLS6 - Remove Swivel Bar; Detail A: 450;600 lbs Lifts; Detail B: 9805 Lift

Reliant Scale RLS6 2 Part No 1114832
Remove the Swivel Bar
 WARNING
Invacare slings and patient lift accessories are specifically designed to be used in conjunction with
Invacare patient lifts. Slings and accessories designed by other manufacturers are not to be uti-
lized as a component of Invacare’s lift system.
NOTE:Forthisprocedure,refertoFIGURE 1.
NOTE:TheReliantScalecannotbeusedinconjunctionwiththeswivelbarsuppliedwiththeInvacare9805Lift.
TheReliantSwivelBar(PartNo.1064518)MUSTbepurchasedandinstalledontheInvacare9805liftinorder
toinstalltheReliantScale.
1. Performoneofthefollowing:
•For450lbsand600lbsReliantLifts‐Removeshoulderbolt,locknut,pinchguardandwasher
whichsecuretheswivelbartotheboommountingbracket.
NOTE:SavetheshoulderboltandlocknuttosecuretheReliantScaletotheboom.Thepinchguardwillnot
beusedwhenthescaleisinstalled.Savepinchguardforfutureuseofswivelbarwithoutscale.
•ForModelNo.9805Lift‐Removeshoulderboltandlocknutwhichsecuretheswivelbartothe
boommountingbracket.
NOTE:SavetheshoulderboltandlocknuttosecuretheReliantScaletotheboom.
NOTE:Removingtheswivelbarhardwarewillreleasetheswivelbar,twonylonwashersandtheswivelbarpin.
Savetheswivelbarpinandthetwonylonwashersforfutureuseoftheswivelbarwithoutthescale.
FIGURE 1 Remove the Swivel Bar
DETAIL “A” - 450 LBS / 600 LBS RELIANT LIFTS
*NOTE:600liftswivelbarnotshown.
Boom Mounting
Bracket
Locknut
(Save for
installing
Scale)
Boom
Pinch
Guard
Shoulder Bolt
(Save for
installing
Scale)
Washer
(Save for
installing
Scale)
Nylon
Washers
Swivel Bar Pin
*450 lbs
Swivel Bar
Swivel Bar
Boom
Shoulder
Bolt
(Save for
installing
Scale)
Locknut
(Save for
installing
Scale)
DETAIL “B” - 9805 LIFT
Boom
Mounting
Bracket
Swivel Bar Pin
Nylon
Washers
NOTE:Somehardwarehasbeen
enlargedforclarificationpurposes.
