Invacare RLS6 - Install Reliant Scale; Detail A: Attaching Scale; Detail B: Attaching Hanger Bar

Part No 1114832 3 Reliant Scale RLS6
Install the Reliant Scale
NOTE:Forthisprocedure,refertoFIGURE 2.
1. PositiontheloadcellassemblyoftheReliantScaleintotheboommountingbracket.RefertoDetail
ʺAʺinFIGURE 2.
NOTE:For9805liftuse1/8‐inchthicknylonwasher.For450lbs/600lbsliftsuse1/4‐inchthicknylonwasher.
2. SecuretheReliantScaletotheboommountingbracketwithashoulderbolt,onesmallsteelwasher,
twonylonwashersandalocknut.Securelytighten.RefertoDetailʺAʺinFIGURE 2forwasher
orientation.
NOTE:Ensuretheshaftoftheshoulderboltpassesthroughbothsidesoftheboommountingbracket.
3. Insertswivelbarpinwithtwonylonwashersthroughtheswivelbar.RefertoDetailʺBʺin
FIGURE 2.
4. Alignthemountingholesintheswivelbarpinwiththemountingholesintheloadcellassembly.
RefertoDetailʺBʺinFIGURE 2.
5. Secureswivelbarpintotheloadcellassemblywiththeprovidedmountingscrewandlocknut.
Securelytighten.RefertoDetailʺBʺinFIGURE 2.
6. Weighthepatient.RefertoOperatingtheScaleonpage 4.
FIGURE 2 Install the Reliant Scale
DETAIL "A" - ATTACHING
THE SCALE
Boom
Boom
Mounting
Bracket
Locknut
Nylon Washer
Reliant
Scale
Nylon
Washer
Shoulder
Bolt
Load Cell
Assembly
Swivel Bar Pin
Reliant Scale
Swivel Bar
Locknut
Mounting
Screw
DETAIL "B" - ATTACHING THE
HANGER BAR
Nylon
Washers
