Invacare Taurus - Disclosure Form

19
ISO 7176 PART 15
REQUIREMENTS FOR INFORMATION DISCLOSURE,
DOCUMENTATION AND LABELLING
MODEL DESIGNATION: TAURUS SCOOTER (HS390)
ISO TEST
METHOD
REQUIREMENT MIN MAX
ISO TEST
METHOD
REQUIREMENT MIN MAX
ISO 7176
Pt 5
Overall Length with Legrest
1235
mm
1235
mm
ISO 7176
Pt 7
Seat Angle Plane
6 6
ISO 7176
Pt 5
Overall Width
628mm 628mm
ISO 7176
Pt 7
Effective Seat Depth
350mm 350mm
ISO 7176
Pt 5
Folded Length
N/A N/A
ISO 7176
Pt 7
Effective Seat Width
340mm 340mm
ISO 7176
Pt 5
Folded Width
N/A N/A
ISO 7176
Pt 7
Seat Surface Height -
Front Edge
583mm 683mm
ISO 7176
Pt 5
Folded Height
N/A N/A
ISO 7176
Pt 7
Backrest Angle
10 10
ISO 7176
Pt 5
Total Weight
78Kg 78Kg
ISO 7176
Pt 7
Backrest Height
450mm 450mm
ʳ
ʳ
ISO 7176
Pt 7
Footrest to Seat
Distance
450mm 550mm
ISO 7176
Pt 1
Static Stability Downhill
30 30
ISO 7176
Pt 7
Leg to Seat Surface
Angle
N/A N/A
ISO 7176
Pt 1
Static Stability Uphill
14.5 28.5
ISO 7176
Pt 7
Armrest to Seat
Distance
210mm 210mm
ISO 7176
Pt 1
Static Stability Sideways
15 17.5
ISO 7176
Pt 7
Front Armrest to
Backrest
430mm 430mm
ISO 7176
Pt 4
Energy Consumption
Range
31.9Km 31.9Km
ISO 7176
Pt 7
Horizontal Location of
Axle
25mm 53mm
ISO 7176
Pt 2
Dynamic Stability Uphill
8 8
ISO 7176
Pt 5
Minimum Turning
Radius
1420
mm
1420
mm
ISO 7176
Pt 10
Obstacle Climbing
55mm 70mm
ISO 7176
Pt 5
Turn Around Width
Limiting Walls
1660
mm
1660
mm
ISO 7176
Pt 6
Maximum Speed Forward
6.4
Km/hr
6.4
Km/hr
ISO 7176
Pt 7
Handrim Diameter
N/A N/A
ISO 7176
Pt 3
Minimum Braking Distance
1.24m 1.24m
ʳ
ʳ
The Wheelchair conforms to the following standards :
ISO 7176 Pt 8 Static, Impact and Fatigue Strength PASS
ISO 7176 Pt 9 Climatic Tests PASS
ISO 7176 Pt 14 Power and Controls PASS
ISO 7176 Pt 16
Resistance to
Ignition
PASS
'
'
'
,
,
,
