11 SETUP/MAINTENANCE
Invacare
3G Storm Series® 110 Part No 1143151
FIGURE8 Disconnecting/Connecting Battery Cables - 22NF Batteries in Single Battery Box
STEPS 5 and 6
Front Battery
Rear Battery
Battery Box Bottom
POSITIVE (+) Battery
Terminal/Post
RED POSITIVE (+) Battery Cable
Battery Box
Top

Battery box top cut away for
clarification purposes only.
Front Battery
Rear Battery
Battery Box
Bottom
NEGATIVE (-)
Battery Terminal/
Post
BLACK NEGATIVE
(-) Battery Cable
Battery Box Top
(Under Side shown)
Fuse Block
RED POSITIVE (+)
Battery Cable
FRONT
STEPS 3 and 4
