8 WHEELCHAIR OPERATION
Invacare
3G Storm Series® 70 Part No 1143151
FIGURE12 Disengaging/Engaging Motor Lock Levers
Towards
Outside of
Wheelchair
ENGAGE (Drive)
Motor Lock Lever
DISENGAGE (Push)
Motor Lock Lever
DETAIL A - 4 POLE MOTORS
DRIVE
PUSH
P/N1114835
ENGAGE
(Drive)
Motor Lock
Lever
DISENGAGE (Push)
Motor Lock Lever
DETAIL B - GB MOTORS
