OPERATING INSTRUCTIONS
NOTE
1
2
3
4
5
6
7
1
Air outlet
2
Operation panel
3
Horizontal airflow control louver
4
Vertical airflow control louver
5
Front panel (upper and lower)
6
Air inlet
All the pictures in this manual are for explanation purpose only.
They may be slightly different from the air conditioner you
purchased(depend on model). The actual shape shall prevail.
Product Overview
Indoor unit
NOTE: This manual does not include Remote Controller Operations, see the
<<Remote Controller Instruction>> packed with the unit for details.
ASSITANT
FUNCTION
TEST RUN
LOCK
ON/OFF MODE FAN SPEED
ADJUST
Outdoor unit
7
8
Drain pipe
9
Connection cable
10
Connection pipe
11
Cut-off valve
Fan hood
1
11
8
9
10
