INVENTOR EVO-12

37
8.2 Parts List
Indoor Unit
Part Code
CEVI-09
1
Decorative Strip
20192292 20192292
1
2
Front Panel
2001232501T 2001232501T
1
3
Filter Sub-Assy
1112208201 1112208201
2
4
Front Case 20012324 20012324
1
5
Guide Louver
10512119 10512119
1
6
Air Louver
10512160 10512160
2
7
Shaft of guide louver
1054202001 1054202001
2
8
Front Panel Assy
2001237601 2001237601
1
9
Drainage Pipe Sub-assy
0523204101 0523204101
1
10
Evaporator Support
24212108 24212108
1
11
Cross Flow Fan
10352423 10352423
1
12
Evaporator Assy
01002270 01002270
1
13
Helicoid ton
g
ue
26112486 26112486
1
14
Rear Case assy 2220211901 2220211901
1
15
Wall Mounting Frame 0125201801 0125201801
1
16
Electric Box Cover
20122106 20122106
1
17
Electric Box Assy
2020225303 2020225302
1
18
Motor Press Plate
26112191 26112191
1
19
Electric Box Cover Sub-Assy
20122109 20122109
1
20
Terminal Board 42011233 42011233
1
21
Crank
73012005 73012005
1
22
Step Motor
1521210701 1521210701
1
23
Pipe plug (outlet)
76712020 76712020
1
24
Electric Box 20112086 20112086
1
25
Motor Sub-Assy 15002002 15002002
1
26
Baffle Plate
26112218 26112218
1
27
Fan Motor
15012093 15012093
1
28
Front Case Assy
2001237501 2001237501
1
29
Remote Controller
30510061 30510061
1
30
Power Cord
400204643 400204643
1
31
Connecting Cable
400205236 400205236
1
32
Screw Cover
24252019 24252019
1
33
Main Board
30138124 30138120
1
34 XY Capacitor
33030013
33030013 1
35 Ambient Temperature Sensor 390000453
390000453
1
36
Fan Bearing 76512210 76512210
1
37 Damping washer sub-assy
76512011 76512011 1
38 Axile Bush sub-assy
10542024 10542024
1
39 Electric Box Sub-Assy
2020225703 2020225702
1
No Description Qty
Exploded Views and Parts list
EVI-09
