INVENTOR NUVI-12WF User Manual

Name
Shape Quantity
1
1
1
(for cooling & heating
models only)
Clip anchor
Mounting plate xing
screw ST3.9 X 25
Remote controller
Fixing screw for remote
controller holder ST2.9 x 10
Remote controller holder
Dry battery AAA.LR03
Seal
Drain joint
Mounting plate
1
Accessories
The air conditioning system comes with the following accessories. Use all of the installation
parts and accessories to install the air conditioner. Improper installation may result in water
leakage, electrical shock and re, or cause the equipment to fail.
5
5
2
1
Optional
Parts
2
 Page 6 
WARNING
2
2
2
2
2
2
1
1
1
Owner’s manual
Installation manual
Remote controller
illustration
 Page 7 
Name
Shape Quantity
Parts you must purchase.
Consult the dealer about
the pipe size.
Connecting pipe
assembly
Liquid side
Gas side
Φ
6.35( 1/4 in)
Φ9.52(3/8in)
Φ9.52(3/8in)
Φ12.7(1/2in)
Φ 16(5/8in)
Appliance shall be stored in a well -ventilated area where the room size corresponds to the
room area as speciec for operation.
For R32 frigerant models:
Appliance shall be installed, operated and stored in a room with a oor area larger than 4m .
Appliance shall not be installed in an unvertilated space, if that space is smaller than 4m .
For R290 refrigerant models, the minimum room size needed:
<=9000Btu/h units: 13m
>9000Btu/h and <=12000Btu/h units: 17m
>12000Btu/h and <=18000Btu/h units: 26m
>18000Btu/h and <=24000Btu/h units: 35m
Φ 19( 3/ 4in)
