AKIMIX Wood Stove Reference P619044
Name:
Guide
No.
Item name
Reference
1
1
Base
F612200U
2
1
Regulator plate
AT610443A
3
1
Heavy duty locking screw
AS618100
4
10
Washer L D8
AV4110080
5
1
Spring
AS750125
6
31
Nut M6
AV7220060
7
4
Foot
F612174U
8
4
M8 locking washer
AV4150080
9
4
TH M08x20 screw
AV8408200
10
1
Front plate
F612201B
11
1
Window regulator
AT610442A
12
1
Air guide
F612213B
13
3
FHC M6x35 screw
AV8636350
14
2
Locking wedge
AT610444
15
1
Locking bracket
AT610441B
16
1
Locking connector
AS610235A
17
2
FHC M6x16 steel screw
AV8636166
18
1
Hearth door
F612202U
19
1
Control rods
AS610234D
20
6
BHC M5x8 screw
AV8685080
21
1
Left-hand side
F612204B
22
1
Internal surface
F612205B
23
4
TH M8x60 screw
AV8408600
24
8
Nut M8
AV7220080
25
4
Washer L D6
AV4110060
26
6
TH M6x20 screw
AV8406200
27
1
Rear
F612206B
28
1
Post-combustion regulator
AT610451A
29
2
Limiter
AT610112A
30
4
TBEHC M6x20 screw
AV8696200
31
4
ThM5x25 screw
AV8405250
32
8
M D5 washer
AV40900050
33
4
M5 nut
AV7100050
34
1
Floor plate
F612209B
35
1
Upper insert
F612177B
36
8
TBEHC M6x30 stainless steel screw
AV8696306
37
1
Hearth grill
F612207B
38
1
Feed channel
F612216U
39
1
Nozzle
F610271B
40
6
M6x30 stud
AV8706300
41
4
M8x40 stud
AV8708400
42
1
Hopper
AT610454D
43
1
Front right-hand side
F612211B
44
2
TH M6x10 screw
AV8406100
45
1
Top
F612214U
46
2
Hinges
AS610120B
47
8
FHC M5x10 screw
AV8635100
48
1
Granule cover
F612215U
49
10
FHC M6x20 screw
AV8636200
