OBLICA | PHAROS INSTALLATION AND USER MANUAL

3. INSTALLATION

3.1 Typical flue kit installation

Cowl (Chinaman Hat)

9” Outer Case

11” Outer Case

9” Outer Case

11” Outer Case

7” Active Flue

7 / 9” Flue

CEILING RING

RUBBER

DEKTITE FLASHING
