Invicta REMILLY User Manual

Wood stove REMILLY Référence: 601384
Code 1
XD, le 03/07/2019 Page 2 of 9
Specific user and installation manual
Please read this additional specific manual and the general manual also provided with the appliance carefully
Specifications as per EN 13240:
8
0
0
366
410
150
Construction specifications:
Rated power 7 kW
Efficiency 78 %
CO Rate% 0.08 %
Flamme Verte classification

Released dust concentration at 13% of O 2 21 mg/Nm
3
Smoke temperature 318 °C
Recommended fuel Wood / 25 cm logs
maximum possible length (horizontally): 34 cm
Smoke mass flow 5.6 g/s
Floor protection
The appliance must not be placed directly on flooring made of combustible materials or that could be damaged by heat.
If this occurs, place the appliance on a 50 cm wide and 50 cm long concrete slab, 45mm thick, covered with a reflective
surface on the appliance side (stainless steel type plate or plate with a glossy ceramic surface), the appliance should be
in the middle of this slab.
Minimum distance from adjacent combustible materials: 60 cm
If the neighbouring walls are made from non-combustible materials that are not damaged by heat (the wall temperature
can reach 200°C), these distances can be reduced to 15 cm.
Extended combustion 8 hours
Appliance weight 72 kg
Connection to the chimney flue using the nozzle
on the top of the appliance
diameter 150 mm
Dimensions h 800 mm len 436 mm depth 364 mm
Door dimensions h 489 mm len 328 mm
Window dimensions h 326 mm len 228 mm
Identification plate Engraved on the underside of the ash pan

Invicta REMILLY Specifications

General

Power	10 kW
Flue diameter	150 mm
Flue location	Top
Weight	116 kg
Fuel	Wood
Body material	Cast iron
Maximum log length	50 cm
Emissions	0.12% CO
Width	550 mm
Burn time	8 hours
