Invicta TI-14 User Manual

S
HAPE
R
Technical Specification
Version 02 03 04 05
35.43 x 43.3 35.43 x 43.3 35.43 x 43.3 35.43 x 43.3
Table dimensions (in)
33.46
33.46
33.46 33.46
Working height (in)
Spindle vertical travel (in)
5.51 5.51 5.51 5.51
Morse taper
#5 #5 #5 #5
Spindle diameter (in)
.75 & 1.25 .75 & 1.25 .75 & 1.25 .75 & 1.25
Useable spindle length (in)
5.31 5.31 5.31 5.31
Table insert diameter (in)
16.53 16.53 12.99 12.99
Spindle speeds (rpm)
Three phase motor power
7.5 HP 7.5 HP 7.5 HP 7.5 HP
Sliding table travel (in)
- -
39.37 39.37
Brake
YES YES YES YES
Micro-adjustable fence
YES YES YES YES
Sliding table (in)
- -
10.82x54.13 10.82x54.13
Spindle Tilting
-
YES - YES
Net weight
1257 lbs 1257 lbs 1389 lbs 1433 lbs
Gross weight
1425 lbs 1433 lbs 1566 lbs 1621lbs
0
3
