BPD series PV pumping inverter Product overview
15
(Unit: mm)
Model
H1
W1
D
H2
W2
Installation
hole
BPD1K5TN(AC)
BPD2K2TN(AC)
280
300
137
131
195
8
H1
W2
H3 H2
D
W1
Figure 2.7 Dimensions of BPD004TNAC
(Unit: mm)
Model
H1
W1
D
H2
W2
H3
Installation
Hole
BPD004TNAC
410
360
154.5
159
260
45
8
