BPD series PV pumping inverter Product overview
6
Model
BPD0K7
TN(AC)
BPD1K5
TN(AC)
BPD2K2
TN(AC)
BPD004
TNAC
BPD2K2
TRAC(S)
BPD004
TRAC(S)
BPD5K5
TRAC(S)
Output wiring
mode
1P2L: 1PH motor 1PH control
2P3L: 1PH motor 2PH control
3P3L: Connected to a 3PH asynchronous
motor
3P3L: Connected to a 3PH
asynchronous motor
Output
frequency (Hz)
1400
Control performance
Control mode
V/F
Motor type
Asynchronous motor (1PH/3PH)
Asynchronous motor (3PH)
Other parameters
Dimensions
(WxDxH) (mm)
255×300
×137
280×300×137
410×360
×154.5
331×360
×154.5
454×360×154.5
Net weight (kg)
6.4
7
13.15
10.1
14.1
Package weight
(kg)
8.5
9
16
12
16
Ingress
protection
rating
IP65
Cooling
Natural cooling
HMI
External LED keypad
Communication terminals
External
communication
RS485/3 digital inputs
Communication
interface
Multi-core waterproof connector
Certification
Standards
CE; EMC meets the requirements of IEC61800-3 C3.
Operating environment
Ambient
temperature
-256C (derated at temperature higher than 45°C)
Altitude
3000 m (derated at altitude higher than 2000 m)
