Goodrive20-EU series VFD Function parameters
62
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P05.18
S3 terminal
switching on
delay time
0.000s
P05.19
S3 terminal
switching off
delay time
0.000s
P05.20
S4 terminal
switching on
delay time
0.000s
P05.21
S4 terminal
switching off
delay time
0.000s
P05.30
HDI terminal
switching on
delay time
0.000s
P05.31
HDI terminal
switching off
delay time
0.000s
P05.32
Lower limit of
AI1
AI1 is set by the analog potentiometer, AI2 is set
by control terminal AI2 and AI3 is set by control
terminal AI3. The function code defines the
relationship between the analog input voltage
and its corresponding set value. If the analog
input voltage beyond the set minimum or
maximum input value, the VFD will count at the
minimum or maximum one.
When the analog input is the current input, the
corresponding voltage of 0 20mA is 0 10V.
In different cases, the corresponding rated value
of 100.0% is different. See the application for
detailed information.
The figure below illustrates different applications:
0.00V
P05.33
Corresponding
setting of the
lower limit of
AI1
0.0%
P05.34
Upper limit of
AI1
10.00V
P05.35
Corresponding
setting of the
upper limit of
AI1
100.0%
P05.36
AI1 input filter
time
0.100s
P05.37
Lower limit of
AI2
0.00V
P05.38
Corresponding
setting of the
lower limit of
0.0%
