Goodrive20-EU series VFD Function parameters
90
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
Setting range of P10.(2n, 1<n<17): -100.0
100.0%
Setting range of P10.(2n+1, 1<n<17): 0.0
6553.5s (min)
P10.34
Acceleration/
deceleration
time selection
of simple PLC
0 7 step
Below is the detailed instruction:
Function
code
Binary bit
Step
ACC/
DEC 0
ACC/
DEC 1
ACC/
DEC 2
ACC/
DEC 3
P10.34
BIT1
BIT0
0
00
01
10
11
BIT3
BIT2
1
00
01
10
11
BIT5
BIT4
2
00
01
10
11
BIT7
BIT6
3
00
01
10
11
BIT9
BIT8
4
00
01
10
11
BIT11
BIT10
5
00
01
10
11
BIT13
BIT12
6
00
01
10
11
BIT15
BIT14
7
00
01
10
11
P10.35
BIT1
BIT0
8
00
01
10
11
BIT3
BIT2
9
00
01
10
11
BIT5
BIT4
10
00
01
10
11
BIT7
BIT6
11
00
01
10
11
BIT9
BIT8
12
00
01
10
11
BIT11
BIT10
13
00
01
10
11
BIT13
BIT12
14
00
01
10
11
BIT15
BIT14
15
00
01
10
11
After the users select the corresponding
acceleration/deceleration time, the combining 16
binary bit will change into decimal bit, and then
set the corresponding function codes.
Setting range: -0x0000 0xFFFF
0x0000
P10.35
Acceleration/
deceleration
time selection
of simple PLC
8 15 step
0x0000
P10.36
PLC restart
mode
0: Restart from the first stage; stop during
running (caused by the stop command, fault or
power loss), run from the first stage after restart.
1: Continue to run from the stop frequency; stop
during running (cause by stop command and
fault), the VFD will record the running time
automatically, enter into the stage after restart
and keep the remaining running at the setting
frequency.
0
