GD200A series VFD Function parameters
-94-
Function
code
Name
Description
Default
value
Modify
to all reading and writing commands of the upper
monitor.
1: Operation without response; The drive only
responds to the reading command other than the
writing command of the drive. The communication
efficiency can be increased by this method.
LED tens place:
0: Communication encrypting invalid
1: Communication encrypting valid
LED hundreds place, indicating RS485
communication device type
0: GD200A
1: GD200A user-defined address
2: CHF100A
Note: When the LED hundreds place is 1, P14.07
and P14.08 are valid.
P14.07
User-defined
address of
running
commands
0x0000–0xffff
0x1000
○
P14.08
User-defined
address of
frequency
setting
0x0000–0xffff
0x2000
○
P17 Group Monitoring function
Function
code
Name
Description
Default
value
Modify
P17.00
Setting
frequency
Display current set frequency of the VFD
Range: 0.00Hz–P00.03
/
●
P17.01
Output
frequency
Display current output frequency of the VFD
Range: 0.00Hz–P00.03
/
●
P17.02
Ramp
reference
frequency
Display current ramp reference frequency of the
VFD
Range: 0.00Hz–P00.03
/
●
P17.03
Output voltage
Display current output voltage of the VFD
Range: 0–1200V
/
●
P17.04
Output current
Display current output current of the VFD
Range: 0.0–3000.0A
/
●
