INVT GD200A-110G/132P-4 User Manual

GD200A series VFD Function parameters
-96-
Function
code
Name
Description
Default
value
Modify
018G/022P and higher models.
Display analog AI1 input signal
Range: 0.00–10.00V
P17.20
AI2 input
voltage
Display analog AI2 input signal
Range: 0.00–10.00V
/
●
P17.21
AI3 input
voltage
Display analog AI2 input signal
Range: -10.00–10.00V
/
●
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.000–50.000kHz
/
●
P17.23
PID reference
value
Display PID reference value
Range: -100.0–100.0%
/
●
P17.24
PID feedback
value
Display PID response value
Range: -100.0–100.0%
/
●
P17.25
Power factor of
the motor
Display the current power factor of the motor.
Range: -1.00–1.00
/
●
P17.26
Current running
time
Display the current running time of the VFD.
Range: 0–65535min
/
●
P17.27
Simple PLC
and the current
step of
multi-step
speed
Display simple PLC and the current step of the
multi-step speed
Range: 0–15
/
●
P17.35
AC input
current
Display the input current in AC side.
Range: 0.0–5000.0A
/
●
P17.36
Output torque
Display the output torque. Positive value is in the
electromotion state, and negative is in the power
generating state.
Range: -3000.0Nm–3000.0Nm
/
●
P17.37
Counting of the
motor overload
0–100 (100 is OL1 fault)
/
●
P17.38
PID output
-100.00–100.00%
0.00%
●
P17.39
Wrong
download of
parameters
0.00–99.99
0.00
●
P24 Group Water supply
Function
code
Name
Description
Default
value
Modify
P24.00
Water supply
selection
0: Disabled
1: Enabled
0
◎
