INVT GD200A-132G/160P-4 User Manual

GD200A series VFD Function parameters
-97-
Function
code
Name
Description
Default
value
Modify
P24.01
Press feedback
source
0: AI1 setting value (implemented through the
analog potentiometer on the keypad for the
0150G/018P and lower models; not available for
the 018G/022P and higher models.)
1: AI2 setting value
2: AI3 setting value
3: HDI setting value
0
○
P24.02
Hibernation
check
0: Hibernate as the setting frequency﹤P24.03
1: Hibernate as the feedback pressure﹥P24.04
0
◎
P24.03
Starting
frequency of
the hibernation
0.00–P00.03 (the max. frequency)
10.00
Hz
○
P24.04
Starting
pressure of
hibernation
0.00–100.0%
50.0%
○
P24.05
Hibernation
delay time
0.0–3600.0s
5.0s
○
P24.06
Hibernation
awake
0: Awake as the setting frequency﹥P24.07
1: Awake as the feedback pressure﹤P24.08
0
◎
P24.07
Awake
frequency
0.00–P00.03 (the max. frequency)
20.00
Hz
○
P24.08
Setting value of
hibernation
awake
0.00–100.0%
10.0%
○
P24.09
Min.
hibernation
time
0.0–3600.0s
5.0s
○
P24.10
Valid auxiliary
motor
P24.10–P24.12 can make three motors to form a
simple system of water supply.
0
○
P24.11
Start/stop delay
time of auxiliary
motor 1
5.0s
○
P24.12
Start/stop delay
time of auxiliary
motor 2
5.0s
○

INVT GD200A-132G/160P-4 Specifications

General

Model	GD200A-132G/160P-4
Rated Power	132kW
Power (Heavy Duty)	160kW
Cooling Method	Forced air cooling
Protection Level	IP20
Storage Temperature	-20°C to +60°C
Output Voltage	0 - Input Voltage
Control Mode	V/F
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Overload, Short circuit
Altitude	≤1000m (above sea level)
