INVT GD200A-1R5G-4

GD200A series VFD Peripheral options and parts
-166-
VFD model
Breaker (A)
Fuse (A)
Rated current of the
reactor (A)
GD200A-0R7G-4
4
5
9
GD200A-1R5G-4
6
10
9
GD200A-2R2G-4
10
10
9
GD200A-004G/5R5P-4
20/25
20/35
18/25
GD200A-5R5G/7R5P-4
25/32
35/40
25/32
GD200A-7R5G/011P-4
32/50
40/50
32/38
GD200A-011G/015P-4
50/63
50/60
38/50
GD200A-015G/018P-4
63/63
60/70
50/65
GD200A-018G/022P-4
63/80
70/90
65/80
GD200A-022G/030P-4
80/100
90/125
80/80
GD200A-030G/037P-4
100/125
125/125
80/98
GD200A-037G/045P-4
125/140
125/150
98/115
GD200A-045G/055P-4
140/180
150/200
115/150
GD200A-055G/075P-4
180/225
200/250
150/185
GD200A-075G/090P-4
225/250
250/300
185/225
GD200A-090G/110P-4
250/315
300/350
225/265
GD200A-110G/132P-4
315/400
350/400
265/330
GD200A-132G/160P-4
400/500
400/500
330/400
GD200A-160G/185P-4
500/500
500/600
400/400
GD200A-185G/200P-4
500/630
600/600
400/500
GD200A-200G/220P-4
630/630
600/700
500/500
GD200A-220G/250P-4
630/700
700/800
500/630
GD200A-250G/280P-4
700/800
800/1000
630/630
GD200A-280G/315P-4
800/1000
1000/1000
630/800
GD200A-315G/355P-4
1000/1000
1000/1000
800/800
GD200A-355G/400P-4
1000/1000
1000/1200
800/1000
GD200A-400P-4
1000
1200
1000
GD200A-400G-4
1000
1200
1000
GD200A-450G-4
1250
1200
1000
GD200A-500G-4
1250
1400
1000
Note: The forward slash "/" is used to distinguish data about G-type VFDs from data about P-type
VFDs.
C.6 Reactors
When the distance between the VFD and motor is longer than 50 m, the parasitic capacitance
between the long cable and ground may cause large leakage current, and overcurrent protection of
the VFD may be frequently triggered. To prevent this from happening and avoid damage to the
