Place the base in the desired location
(either on a horizontal or vertical surface)
and apply pressure for at least 10
seconds.
4b
6
Plug the power supply into a power
outlet. The LED on the key will be
red.
7
To activate the Detacher, hold a charged
and coded OneKEY close to the nose of
the Detacher key. Press the button on
the OneKEY. The LED on the Detacher
key will turn blue when successfully
coded.
5
Plug the Detacher’s power cable into
the PS18V power supply.
8
Place the Detacher key onto the
base.
4a
Adhesive Mount: Peel the clear
lm from the 3 adhesives on the
bottom of the base
4c
Insert one side of the pad into the
rim of the base. The tabs on the pad
will t into the slots on the inner rim
of the base.
4d
Apply pressure around the edge of
the pad to fully secure the pad in the
rim of the base.
