InWin 309 - I;O Wires Installation

6
I/O Wires Installation
PORT2_L
SENSE_SEND
PORT2_R
PORT1_R
PORT1_L
BLUE
PURPLE
YELLOW
RED
GREEN
10
8
6
4
2
SENSE2_R
KEY
SNAS1_R
PRESENCE#
GND
BROWN
WHITE
ORANGE
BLACK
9
7
5
3
1
HD Audio Header
Vbus
IntA_P1_SSRX-
IntA_P2_SSRX+
GND
IntA_P1_SSTX-
IntA_P1_SSTX+
GND
IntA_P1_D-
IntA_P1_D+
ID USBOC-
USB3.0 Header
1
2
3
4
5
6
7
8
9
10
Vbus
IntA_P2_SSRX-
IntA_P2_SSRX+
GND
IntA_P2_SSTX-
IntA_P2_SSTX+
GND
IntA_P2_D-
IntA_P2_D+
19
18
17
16
15
14
13
12
11
PIN#1 PIN#19
PIN#10
PIN#11
POWER LED
(Depend On Motherboard)
POWER SW
RESET SW
H.D.D LED
