Port Switching
Port Switching
You can switch port via front panel pushbutton or hotkey commands.
Port Switching via Front Panel Pushbutton
Mode1 (Default)
Function Description
Switch All Focus (KVM, Audio and USB) Pressandholdthespecicpushbuttonfor2seconds
Switch KVM Focus Pressthespecicpushbuttononce
Switch Audio Focus Pressthespecicpushbuttontwicerapidly
Mode2*
Function Description
Switch All Focus (KVM, Audio and USB) Pressthespecicpushbuttononce
Switch KVM Focus Pressandholdthespecicpushbuttonfor2seconds
Switch Audio Focus Pressthespecicpushbuttontwicerapidly
*Please refer to the HSM (Hotkeys Setting Mode) section for details about how to switch the front panel
pushbutton into Mode2.
