11
No. Component Description
1 Port LED’s These port selection push buttons each contain 2 LEDs.
An orange LED indicates that a computer is connected to the corresponding •
port.
A green LED indicates that the computer connected to the corresponding •
port has focus.
Simultaneously pressing port LEDs 1 & 2 resets the console keyboard and •
mouse.
Simultaneously pressing port LEDs 15 & 16 on the GCS1716 starts Auto •
Scan mode. See F7: SCAN
2 Reset
Button
Pressing this button performs a system reset. When the system is reset, the
GCS1716 beeps, and then the KVM port LEDs ash in succession until the reset
is completed. After the reset is complete, you can login again.
Note: This button is semi-recessed and must be pushed with a small object,
such as the end of a paper clip or a thin ballpoint pen.
3 USB Port USB peripherals (ash drive, CD-ROM, etc.) plug into this port.
