No Components Description
1 KVM Ports The cables that link to the computers plug in here.
Note: The shape of these 15-pin connectors has been specically modied
so that only custom KVM cables designed to work with this switch can be
plugged in. Do NOT attempt to use ordinary 15-pin VGA connector cables to
link these ports to the computers.
2 Grounding
Terminal
The grounding wire used to ground the GCS1716 attaches here.
3 Cable Tie Slot If you want to use a cable tie to gather the cables together, you can run it
through this slot to attach it to the unit.
4 Power Jack The power adapter cable plugs in here.
5 Console Port The custom console cable set that is provided to attach the console monitor,
keyboard, and mouse plugs in here.
14
