IOGear GCS2HU - Overview

6
Overview
1. PC 1 LED
2. PC 2 LED
3. Console USB Mouse Port
4. Console HD Port
5. Console USB Keyboard Port
6. Console Speaker Port
7. Console Microphone Port
8. CPU Audio connector
9. CPU USB Keyboard connector
10. CPU HD connection
11. CPU USB Keyboard connector
12. CPU Microphone connector
13. Remote Switch Button
8
10
9 11 12 134
2
3
1
5 6 7
