ION iLP - Specifications

31
SPECIFICATIONS
Power: 12V DC, 1A, center pin-positive, tip-negative
Cartridge Type: Ceramic cartridge
Stylus Tip: Diamond tip
Track Force: 5 grams nominal (4-6 grams)
Output Voltage: ( at 1 kHz=3.54 cm/sec) 200-300 mV
Channel Balance: ( at 1 kHz) <=3dB
Channel Separation: (at 1 kHz) >=15dB
Frequency Response: 80-10,000Hz (+-7dB)
Dimensions: 15" x 12.5" x 4" (381 mm x 317.5 mm x 101.6 mm)
Weight: 7 lbs. (3.2 kg)
