Appendix (English)
Technical Specifications
Output Power
500 W (Peak)
Max SPL (@ 1 m)
116 dB peak, 110 dB continuous C-weighted, free space
Low Frequency
15” (381 mm) woofer
High Frequency
1” (25 mm) tweeter
Crossover
2.2 kHz
Frequency Response
55 Hz – 20 kHz (+3 dB)
Frequency Range
45 Hz – 22 kHz (@ -10 dB)
Horn Coverage
80/100° H x 60° V, nominal (@ -6 dB)
Input
Gain Range: -∞ to +10 dB (microphone/line)
Max Input Level: +10 dBu
Impedance: 22 KΩ
External Controls
Channel volume, master volume, power on/off with LED, clip limiter with
LED, echo, 2-band equalizer, mode, play/pause, repeat, previous track,
next track
Connectors
(3) XLR inputs (2 dynamic microphone/line, 1 line)
(2) 1/4” (6.35 mm) TRS inputs
(1) 1/8” (3.5 mm) TRS input
(1) XLR mix output
(1) SD card slot
(1) USB port (host)
(1) IEC power connection
Bluetooth* Profile: A2DP
Module: Bluetooth 4.2
Speed: 3 Mbps
Range: Up to 100 feet / 30.5 meters*
USB/SD Card Audio: Music playback from USB drive or SD card
Supported File System: FAT32
Supported File Types: MP3, WAV, WMV, FLAC, APE
Maximum File Size: < 16 GB
Maximum USB Drive / SD Card Capacity: < 16 GB
