ION Max LP Service Manual

BOM for IT54 2014.1.18 001F013190110
303A40107502 100uF +80/-20% 16V 5*11 4 EC2/EC3/EC4/EC5
DC Socket 329A10000501 DC-005 2.1MM 1 J1
RCA socket 329A10020401 RCA-204-H 1 J6
USB socket 329A10000001 USB-BM 1 J8
phone socket 329A14130601 ST-413-06 1 PJ1
6P lines 320A01500601
1
6P2H/2.5mm L=150mm UL1007
24AWG +AWG2547 28AWG
1
5P lines 320A02500501
1
5P2H/2.5mm L=250mm UL1007
24AWG +AWG2547 28AWG
1
PCB for AMP 301A01319B02
1
-1319 AMP PCB Rev:2.0 FR-
1/D.S. T1.0mm UL94-V0
1AMP PCB
302A20047101 4.7R ±1% SMT0603 2 R63/R64
302A20222101 2.2K ±1% SMT0603 4 R61/R62/R65/R66
302A20153101 15K ±1% SMT0603 2 R59/R60
303A20101402 101 ±20% SMT0603 2 C55/C56
303A20104402 104 ±20% SMT0603 3 C57/C58/C59
303A20105402 105 ±20% SMT0603 4 C51/C52/C53/C54
303A40107502
1
100UF +80/-20%/16V 5 EC9/EC10/EC11/EC
12/EC13
303A40477502 470UF +80/-20%/16V 3 EC6/EC7/EC8
Plug in IC 306A12208227 TA8227 HDIP-12 1 U5
Plug in socket 331A05008001 5P/2.5mm 直针 1 CN3
Plug in socket 331A05007001 5P/2.0mm 直针 1 CN4
Plug in socket 331A04005001 4P/2.0MM 直针 1 CN5
phone scoket 329A14130602 ST-413-06W 1 PJ2
301A13007B01
1
-13007 PCB Rev:1.1 FR-1/S.S.
T1.6mm UL94-V0
1
301A13007B02
1
-13007 PCB Rev:1.1 FR-1/S.S.
T1.6mm UL94-V0
1
VR 333A0000A50 RV16322GO A50K 1 VR1
5P lines 320A01500501
1
5P2.0mm L=150mm AWG2547
28AWG
1 CN6
4P Lines 320A02200401
1
4P1H/2.0mm L=220/280mm
UL1007 24AWG
1 SPEAKER
SPEAKER 323A00000803 8Ω3W S1305-13 2
POWER 308A00121001 TEKA012-1201000UK 1
CD 336A01013191 1
USB CABLE LIEN 339A01319101
1
24AWG
A公+B公+磁环,L=1.5M黑色
1
PCB FOR Volume
MLCC
SMD RESISTOR
Plug in RB
第2页

ION Max LP Specifications

General

Type	Belt-drive turntable
Speeds	33 1/3, 45, 78 RPM
Built-in Speakers	Yes
USB Output	Yes
RCA Output	Yes
Headphone Output	Yes
Software Included	EZ Vinyl/Tape Converter
Built-in Preamp	Yes
Cartridge Type	Ceramic
USB Recording	Yes
Pitch Control	No
