4
Features
1. Platter – Place your record here.
2. 45 RPM Adapter Holder – Holds the
included 45 RPM adapter. When not
using the adapter, please place it in this
holder.
3. Tonearm – The tonearm can be raised
and lowered by hand, or by pressing the
raise / lower lever. Please note that the
tonearm needs to be moved away from
resting position (on the arm clip) for the
turntable motor to activate. When the
tonearm is placed back in its resting
position, the turntable motor will
deactivate.
4. Arm Clip – This specially designed arm
clip secures the tonearm while at rest or
when not in use. The arm clip has been
designed to remain in the up position
while unlocked.
5. Raise / Lower Lever – Raises and lowers
the tonearm.
6. 33 / 45 / 78 Switch* – This switch controls
the RPM of the turntable platter.
Note: For best results when playing 78 RPM
vinyl records, use a 78 stylus (sold
separately). Only use a 78 stylus with 78
RPM vinyl records. Purchase the iCT06rs 78 stylus at
ionaudio.com/ict06rs.
7. Autostop switch – This switch turns autostop on or
off. When autostop is on, the platter will start spinning
when the tonearm is placed over the record and stop
spinning when the record has reached the end. (When
autostop is off, the platter will always spin regardless
of the position of the tonearm.)
Note: If your vinyl record stops before it reaches the
end of the music, turn Autostop to the off position for
this particular record. This is generally recommended
for 45 RPM records.
8. RCA Output** – The audio from a playing vinyl record
is sent to this line-level coaxial audio output. This must
not be connected to phono level devices.
9. USB Audio Output – Use the included USB cable to
connect your turntable to your computer. The USB
connection will send audio from the turntable to your computer. Please see the Using Pure LP With
Your Computer section of this manual for information.
10. Power – Use the included adapter to connect to wall power.
11. Power Button – Press this button to turn PURE LP on/off.
7
2
7
1
7
3
7
4
7
5
7
6
7
7
PURE LP
IMPORTANT: Remove the plastic
cartridge cover (needle cover) before
o
the turntable.
**WARNING: The RCA outputs are LINE
level. Please only connect these to LINE
level inputs. You may damage your
receiver if you plug in a LINE level device
into a PHONO level input.
* If needed, you may adjust the speed of
the turntable platter. On the underside of
PURE LP, remove the rubber pads and
tighten/loosen the appropriate screw with
a screwdriver.
8
9
10
11
