Bill of Materials (BOM)
Part. No. Material nam
e
Spec. Unit Qty. Note
27.1.003.0221 IPA70 Amplifier PCBA IPA70/Amp PCBA, ROHS, REACH PCS 1
17.1.004.0022 Concrete resistor 3.3 ohm, 5W, ±5%, H25 x D10 x W13mm,
ROHS, REACH
PCS 1 R324
17.1.004.0023 wire-wound resistor 0.22ohm, 2W, ±1%, ROHS, REACH PCS 1 R312
17.1.006.0002 Chip carbon film resistor 0, 1/10W, ±5%, 0603, YAGEO, braid,
ROHS, REACH
PCS 1 R320
17.1.006.0005 Chip carbon film resistor 1K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 4 R307, R308,
R316, R328
17.1.006.0012 Chip carbon film resistor 10, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R322
17.1.006.0014 Chip carbon film resistor 10K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 5 R306, R313,
R317, R318,
R323
17.1.006.0077 Chip carbon film resistor 100, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R329
17.1.006.0079 Chip carbon film resistor 100K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 3 R314, R315,
R327
17.1.006.0215 Chip carbon film resistor 10K, 1/10W, ±1%, 0603, YAGEO, braid,
ROHS, REACH
PCS 1 R304
17.1.006.0247 Chip carbon film resistor 15K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R305
17.1.006.0261 Chip carbon film resistor 220, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R325
17.1.006.0420 Chip carbon film resistor 1.5K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R302
17.1.006.0475 Chip carbon film resistor 680, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 2 R301, R326
17.1.006.0521 Chip carbon film resistor 470K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R310
17.1.006.0524 Chip carbon film resistor 2K, 1/4W, ±1%, 1206, braid, ROHS,
REACH
PCS 1 R309
17.1.006.0526 Chip carbon film resistor 162K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R311
17.1.006.0527 Chip carbon film resistor 270, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R303
17.1.050.0145 Electrolytic capacitor 1000uF, 25V, aluminum electrolytic,
±20%, D10*L17, 5mm, feet length 3.5mm,
40+105, ROHS, REACH
PCS 1 C309
17.1.065.0012 Chip electrolytic capacitor 100uF, 16V, aluminum electrolytic, ±20%,
SMD D6.3xL5.4, 105, braid, ROHS,
REACH
PCS 1 C308
17.1.065.0013 Chip electrolytic capacitor 220uF, 16V, aluminum electrolytic, ±20%,
SMD D6.6xL6.6, 105, braid, ROHS,
REACH
PCS 1 C301, C318,
C324
17.1.066.0008 Chip ceramics capacitor 101, 50V, X7R, ±10%, 0603, 125, braid,
ROHS, REACH
PCS 8 C3, C4, C5, C6,
C8, C9, C10,
C11
17.1.066.0009 Chip ceramics capacitor 102, 50V, X7R, ±10%, 0603, 125,
YAGEO, braid, ROHS, REACH
PCS 2 C317, C325
17.1.066.0010 Chip ceramics capacitor 103, 50V, X7R, ±10%, 0603, 125,
YAGEO, braid, ROHS, REACH
PCS 2 C305, C307
17.1.066.0012 Chip ceramics capacitor 104, 50V, X7R, ±10%, 0603, 125, braid,
ROHS, REACH
PCS 6 C302, C304,
C316, C321,
C322, C326
17.1.066.0015 Chip ceramics capacitor 105, 25V, X5R, ±10%, 0603, 85, YAGEO,
braid, ROHS, REACH
PCS 9 C310, C311,
C312, C313,
C314, C315,
C319, C327,
C328
