ION TAILGATER GO Service Manual

17.1.066.0062 Chip ceramics capacitor 225, 16V, X5R, ±10%, 0603, 85, braid,
ROHS, REACH
PCS 2 C320, C323
17.1.066.0065 Chip ceramics capacitor 106, 10V, Y5V, +80%-20%, 0805, 85,
braid, ROHS, REACH
PCS 1 C303
17.1.066.0077 Chip ceramics capacitor 106, 25V, X5R, ±10%, 1206, 85, braid,
ROHS, REACH
PCS 1 C306
17.1.080.0020 DIP Power Inductor 11uHx2, ±10%, φ0.7mm, 20mΩ,
φ13x7mm, TC10*6*4-11UH, ROHS,
REACH
PCS 2 L1, L2
17.1.086.0074 Chip Power Inductor 100UH, ±10%, 300mΩ, 1.5A, 10×5.5mm,
ROHS, REACH
PCS 1 L301
17.1.086.0107 Chip Power Inductor 15UH, ±20%, 42mΩ, 6A, 11.5x10.3x4mm,
braid, ROHS, REACH
PCS 2 L302, L303
17.1.089.0001 Chip Bead 100M/600Ω, ±20%, 0.5Ω, 200mA, 0603,
braid, JHFB1608B601MB, ROHS,
REACH
PCS 1 L27
17.1.089.0009 Chip Bead 100M/2.5KΩ, ±25%, 1.5Ω, 30mA, 0603,
braid, MGGB1608M252HT-LF, ROHS,
REACH
PCS 1 L4
17.1.089.0026 Chip Bead 100M/600Ω, ±25%, 0.10Ω, 2A, 1206,
braid, MGLB3216M601T2R0-LF, ROHS,
REACH
PCS 1 L3
17.1.089.0029 Chip Bead 100M/120Ω, ±25%, 小于0.1Ω, 4A, 1206,
braid, MGLB3216M121T4R0-LF, ROHS,
REACH
PCS 2 L304, L305
17.1.129.0001 Chip diode 1N4148, 150mA, 75V, LL-34, ROHS,
REACH
PCS 1 D301
17.1.129.0011 Chip schottky diode SS24, 2A, 40V, DO-214AC, braid, 3x6mm
(SMA), ROHS, REACH
PCS 4 D302, D303,
D304, D305
17.1.151.0003 Chip audion 8050 SOT-23 (RoHS，Reach) PCS 2 Q304,Q308
17.1.151.0014 Chip audion MMBT3904 SOT-23 NXP (RoHS，Reach) PCS 2 Q302,Q306
17.1.151.0017 Chip audion PNP, MMBT3906, SOT-23, braid, ROHS,
REACH
PCS 1 Q303
17.1.170.0135 IC IC LM317 ST TO-220 (RoHS，Reach) PCS 1 IC304
17.1.171.0446 Chip IC AMP IC, AD52580, TSSOP-28, ESMT,
braid, ROHS, REACH
PCS 1 IC303
17.1.171.0447 Chip IC LD1117AL-ADJ-A，braid (RoHS，Reach) PCS 1 IC301
17.1.171.0462 Chip IC Battery management IC LS976-F79 SOP8
(RoHS，Reach)
PCS 1 IC302
17.1.177.0035 Chip field-effect tube P channel, -4.6A, -30V, WPM3401, SOT-
23-3L, WILL, braid, ROHS, REACH
PCS 2 Q301,Q307
17.1.177.0040 Chip field-effect tube P channel, 4A, 30V, WPM9435, SOP-8,
WILL, braid, ROHS, REACH
PCS 1 Q305
17.1.261.0709 Double glass fiber board IPA70-01-A0D, L81 x W60.5 x H1.6mm,
FR-4, 35um, AMP board, ROHS, REACH
PCS 1
17.1.313.0003 2P socket 2P/2.54mm white TJC3-2A-1
(RoHS
，Reach)
PCS 1 JACK303 driver
output
17.1.313.0009 2P socket 2P/3.96mm white (RoHS，Reach) PCS 1 JACK301 battery
connection
17.1.313.0010 2P socket 2P/2.54mm red (RoHS，Reach) PCS 1 JACK302 power
input
17.1.313.0104 3P socket 3P/2mm red (RoHS，Reach) PCS 1 JACK10
17.3.005.0014 2P wire L150mm, one end of pin, one end plug,
2P/2.54mm，red/black 22# 2468
(RoHS，Reach)
PCS 1 CON302 5V
charging out
