ION TAILGATER GO Service Manual

17.3.005.0245 8P wire L150mm, red and white wire, one end of
pin, one end plug, 8P/2.0mm, 26#2468,
ROHS, REACH
PCS 1 CON301 connect
to main board
17.5.008.0150 Heatsink F1500U/45x23.5x16 (mm), aluminium
1.6mm, ROHS, REACH
PCS 1 For LM317 IC
27.1.005.0082 UI display PCBA IPA70/UI display PCBA, ROHS, REACH PCS 1
17.1.006.0002 Chip carbon film resistor 0Ω, 1/10W, ±5%, 0603, YAGEO, braid,
ROHS, REACH
PCS 1 R26
17.1.006.0005 Chip carbon film resistor 1K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 7 R12, R20, R27,
R55, R56, R57,
R69
17.1.006.0014 Chip carbon film resistor 10K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 22 R15, R21, R28,
R34, R35, R40,
R41, R42, R43,
R47, R48, R49,
R52, R54, R59,
R60, R64, R66,
R67, R68, R85,
R86
17.1.006.0015 Chip carbon film resistor 12K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R6
17.1.006.0019 Chip carbon film resistor 15K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R14
17.1.006.0030 Chip carbon film resistor 22K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R8
17.1.006.0039 Chip carbon film resistor 3.3K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R71
17.1.006.0041 Chip carbon film resistor 33K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 2 R53, R83
17.1.006.0045 Chip carbon film resistor 3.9K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R39
17.1.006.0049 Chip carbon film resistor 47Ω, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R75
17.1.006.0053 Chip carbon film resistor 47K, 1/10W, ±5%, 0603, YAGEO, braid,
ROHS, REACH
PCS 9 R7, R19, R25,
R29, R30, R79,
R80, R106, R107
17.1.006.0055 Chip carbon film resistor 49.9K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 2 R81, R89
17.1.006.0061 Chip carbon film resistor 5.6K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 3 R9, R11, R38
17.1.006.0063 Chip carbon film resistor 56K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 2 R4, R18
17.1.006.0077 Chip carbon film resistor 100Ω, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 4 R36, R44, R45,
R65
17.1.006.0079 Chip carbon film resistor 100K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 7 R2, R5, R10,
R37, R70, R72,
R76
17.1.006.0085 Chip carbon film resistor 220Ω, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R17
17.1.006.0117 Chip carbon film resistor Res 56Ω 1/8W ±5% 0805 SMD
(RoHS，Reach)
PCS 1 R22
17.1.006.0127 Chip carbon film resistor 22Ω, 1/10W, ±5%, 0603, YAGEO, braid,
ROHS, REACH
PCS 2 R46, R50
17.1.006.0150 Chip carbon film resistor 3.6K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R61
17.1.006.0199 Chip carbon film resistor 150K, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R16
17.1.006.0215 Chip carbon film resistor 10K, 1/10W, ±1%, 0603, YAGEO, braid,
ROHS, REACH
PCS 4 R31, R32, R33,
R63
