ION TAILGATER GO Service Manual

17.1.006.0220 Chip carbon film resistor 75K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R84
17.1.006.0231 Chip carbon film resistor 43.2K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R82
17.1.006.0235 Chip carbon film resistor 4.7M, 1/10W, ±5%, 0603, braid, ROHS,
REACH
PCS 1 R3
17.1.006.0245 Chip carbon film resistor 100K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R24
17.1.006.0306 Chip carbon film resistor 4.7K, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 2 R51, R73
17.1.006.0475 Chip carbon film resistor 680Ω, 1/10W, ±1%, 0603, braid, ROHS,
REACH
PCS 1 R74
17.1.006.0518 Chip carbon film resistor 487K ±1% 0603 (RoHS，Reach) PCS 1 R23
17.1.030.0086 Potentiometer B type, 20K, L20mm, diameter 12.5mm,
ROHS, REACH
PCS 2 VR1,VR2
17.1.065.0006 Chip electrolytic capacitor 100uF, 10V, aluminum electrolytic, ±20%,
SMD D5xL5, 105, braid, ROHS, REACH
PCS 1 C31
17.1.065.0013 Chip electrolytic capacitor 220uF, 16V, aluminum electrolytic, ±20%,
SMD D6.6xL6.6, 105, braid, ROHS,
REACH
PCS 2 C62, C67
17.1.066.0008 Chip ceramics capacitor 101, 50V, X7R, ±10%, 0603, 125, braid,
ROHS, REACH
PCS 26 C11, C16, C20,
C21, C23, C29,
C30, C32, C42,
C47, C59, C65,
C66, C68, C69,
C70, C75, C77,
C78, C79, C81,
C83, C85, C86,
C89, C90
17.1.066.0009 Chip ceramics capacitor 102, 50V, X7R, ±10%, 0603, 125,
YAGEO, braid, ROHS, REACH
PCS 2 C52, C53
17.1.066.0012 Chip ceramics capacitor 104, 50V, X7R, ±10%, 0603, 125, braid,
ROHS, REACH
PCS 11 C9, C27, C33,
C40, C48, C60,
C63, C71, C72,
C73, C76
17.1.066.0015 Chip ceramics capacitor 105, 25V, X5R, ±10%, 0603, 85, YAGEO,
braid, ROHS, REACH
PCS 11 C3, C13, C22,
C36, C37, C39,
C41, C57, C74,
C84, C87
17.1.066.0027 Chip ceramics capacitor 222, 50V, X7R, ±10%, 0603, 125,
YAGEO, braid, ROHS, REACH
PCS 1 C2
17.1.066.0036 Chip ceramics capacitor 33P, 50V, NPO, ±5%, 0603, 125, braid,
ROHS, REACH
PCS 11 C1, C14, C17,
C24, C25, C26,
C28, C43, C44,
C45, C56
17.1.066.0039 Chip ceramics capacitor 334, 16V, X7R, ±10%, 0603, 125, braid,
ROHS, REACH
PCS 1 C61
17.1.066.0058 Chip ceramics capacitor 226, 6.3V, X5R, ±20%, 0805, 85, YAGEO,
braid, ROHS, REACH
PCS 3 C12, C15, C58
17.1.066.0075 Chip ceramics capacitor 20P, 50V, NPO, ±5%, 0603, 125, braid,
ROHS, REACH
PCS 2 C7, C18
17.1.066.0097 Chip ceramics capacitor 106, ±20%, 6.3V, X5R, 0603, 85, braid,
ROHS, REACH
PCS 12 C4, C5, C6, C19,
C34, C35, C38,
C46, C54, C55,
C64, C80
17.1.066.0155 Chip ceramics capacitor 106, 16V, X5R, ±10%, 0805, 85, braid,
ROHS, REACH
PCS 2 C49, C51
17.1.066.0195 Chip ceramics capacitor 475, 16V, X5R, ±10%, 0603, 125,
YAGEO, braid, ROHS, REACH
PCS 1 C10
17.1.086.0041 Chip Power Inductor 22uH, ±10%, 1.1Ω, 5mA, 0805,
MGFI2012E220KT-LF, ROHS, REACH
PCS 2 L23, L24
