ION TAILGATER GO Service Manual

17.1.089.0009 Chip Bead 100M/2.5KΩ, ±25%, 1.5Ω, 30mA, 0603,
braid, MGGB1608M252HT-LF, ROHS,
REACH
PCS 15 L1, L2, L3, L4,
L5, L6, L7, L12,
L13, L14, L15,
L16, L18, L19,
L20
17.1.103.0010 Quartz crystal Oscillator 32.768KHz, ±20PPM, ROHS, REACH PCS 1 X1
17.1.129.0001 Chip diode 1N4148, 150mA, 75V, LL-34, ROHS,
REACH
PCS 2 D2, D5
17.1.129.0008 Chip schottky diode BAT54S, 200mA, 30V, SOT23, GSME,
braid, ROHS, REACH
PCS 1 D1
17.1.129.0012 Chip schottky diode BAT54CN3, 200mA, 30V, SOT-23,
ROHS, REACH
PCS 2 D3, D4
17.1.151.0003 Chip audion 8050 SOT-23 (RoHS，Reach) PCS 8 Q1,Q2,Q3,Q4,Q
6,Q7,Q8,Q9
17.1.171.0012 Chip IC LED drive, CS1628, SOP-28, braid
(RoHS，Reach)
PCS 1 IC9
17.1.171.0276 Chip IC(braid) HT4560 SOP braid (RoHS，Reach) PCS 2 IC2,IC7
17.1.171.0447 Chip IC(braid) LD1117AL-ADJ-A，TO252，braid
(RoHS，Reach)
PCS 1 IC8
17.1.171.0597 Chip IC Radio, KT0913, SSOP16L, ROHS,
REACH
PCS 1 IC10
17.1.171.0713 Chip IC(MCU) MCU, MINI54ZDE, QFN32, NUVOTON,
ROHS, REACH
PCS 1 IC1
17.1.171.0849 Chip IC Power management (LDO), BM1117N-
3.3, SOT-223, braid, ROHS, REACH
PCS 3 IC3,IC4,IC5
17.1.171.0850 Chip IC Power management (LDO), BM1117N-5,
SOT-223, braid, ROHS, REACH
PCS 1 IC6
17.1.177.0035 Chip field-effect tube P channel, -4.6A, -30V, WPM3401, SOT-
23-3L, WILL, braid, ROHS, REACH
PCS 3 Q10,Q11,Q12
17.1.220.0046 Chip fuse 2.5A, 250V, NA, 1812, MSMD125-
1812/2.5A (RoHS, Reach), ROHS
PCS 1 F1
17.1.241.0026 LED Display LED display, IPA70, 5V, blue, L63 X W17
X H18 mm, ROHS, REACH
PCS 1 LED1
17.1.261.0710 Double glass fiber board IPA70-02-A0D, L163.5 x W74 X H1.6mm,
FR-4, 35um, ROHS, REACH
PCS 1
17.1.311.0018 5P 3.5-type socket φ3.5mm, black, 5P 3.5 type socket, 5P,
[PJ-30580], ROHS, REACH
PCS 1 JACK6 AUX
input
17.1.313.0010 2P socket 2P/2.54mm red (RoHS，Reach) PCS 1 JACK1 5V
charging out
17.1.313.0014 3P socket 3P/2mm black (RoHS，Reach) PCS 2 JACK2,JACK7
17.1.313.0037 8P socket 8P/2mm black (RoHS，Reach) PCS 1 JACK3 connect
to Amp board
17.1.321.0020 USB Jack USB-010, 12.5x5.12x15mm, black, USB
socket, PIN6, ROHS, REACH
PCS 1 JACK4 USB
socket
17.3.005.0484 3P socket L250mm, red/black/white, one end
pin，one end plug，3P/2.0mm, 26#,
3PIN, ROHS, REACH
PCS 1 JACK5 FM
antenna
27.1.032.0067 BT module FD-BT06H-A-H1/BT module PCS 1 U4
17.1.006.0265 Chip carbon film resistor 0Ω, 1/16W, ±5%, 0402, braid, ROHS,
REACH
PCS 1 R11
17.1.006.0269 Chip carbon film resistor 2.2K, 1/16W, ±1%, 0402, braid, ROHS,
REACH
PCS 3 R6 R7 R8
17.1.066.0115 Chip ceramics capacitor 104, 16V, X7R, ±10%, 0402, 125,
YAGEO, braid, ROHS, REACH
PCS 2 C5 C15
17.1.066.0139 Chip ceramics capacitor 103, 50V, X7R, ±10%, 0402, 125,
YAGEO, braid, ROHS, REACH
PCS 4 C1 C10 C12 C13

ION TAILGATER GO Specifications

General

Brand	ION
Model	TAILGATER GO
Category	Speakers
Language	English
