ION Tailgater iPA77 User Manual

K3 Material No. Material Name Description
Quantity
27.1.003.0186 Amplifier PCBA IPA77/ main amplifier board,ROHS,REACH
1
27.1.005.0047 UI PCBA IPA77/ UI board, with MCU and FW, Bluetooth pairing
name: Tail
g
ater
,
ROHS
,
REACH
1
17.1.241.0018 LED Display IPA77/ Display,5V,3.5mm, Blue,L63 X W17 X
H13.5mm
,
ROHS
,
REACH
1
27.1.022.0002 IPA77 Mic PCBA IPA77/ Mic board,ROHS,REACH
1
17.1.321.0020 USB socket 12.5x5.12x15mm,black,ROHS,REACH
1
17.1.320.0009 Power socket 33.5 X 30.5 X23mm,black 3PIN,ROHS,REACH
1
17.1.192.0005 Power Switch 250V AC6A 125V AC10A 240VAC [KCD1-B3](with UL,
TUV com
p
liance
)
(
RoHS，Reach
)
1
17.1.220.0048 Fuse tube 800mA/250V,φ5 L20mm,glass,ROHS,REACH
1
27.1.018.0064 Power PCBA IPA77/ Power board, ROHS,REACH
1
27.1.032.0085 BT modual FD-BT06H-C-H1/BT modual,ROHS,REACH
1
17.1.292.0023 BT antenna L=130mm,black,thickness 1mm,ROHS,REACH
1
27.1.032.0070 NFC modual NFC TAG 30x22x0.6mm, Chip NXP Ntag203,
(
RoHS
,
Reach
)
1
27.8.062.0026 Bass driver 6.5',4Ω30W,black,FD165-14BEH,ROHS,REACH
1
27.8.920.0014 Tweeter driver φ20,4Ω15W,silk,black,FDG20-14EHR,ROHS,REACH
1
17.1.087.0023 Magnetic bar magnetic bar for AM, 10 x 80mm,ROHS,REACH
1
27.4.020.0181 Bracket for
ma
g
netic bar
IPA77/L35*W11*H14.8mm,ABS, black,ROHS,REACH
2
17.7.032.0196 Vynil wrap IPA77/L261*W21.35*H21.35mm,PVC, T=1.0mm,texture
MT11020
,
ROHS
,
REACH
3
17.7.032.0197 PC Lens IPA77/L227.3*W53.71*H0.5mm,transparent
PC，T=0.5mm,with protective film,silkscreen:TAILGATER
AUX MIC VOLUME Bluetooth RADIO FM/AM/OFF
etc.Pantone Cool Grey 6C,ROHS,REACH
1
27.4.013.0289 Buttons IPA77/L104.1*18.8*H11.8mm,ABS,black,with texture
MT11010
,
ROHS
,
REACH
1
27.4.014.0150 Knob cap
IPA77/φ28.47*12mm,ABS，black with texture MT11020
and
p
olished at to
p
eara
,
ROHS
,
REACH
2
27.4.024.0178 Top panel IPA77/L312.57*W234.78*H68.5mm,ABS, black,
T=3.0mm,texture MT11020 and glossing lines, Logo
silkscreen 877C
,
ROHS
,
REACH
1
27.4.042.0104 Side handle IPA77/L127.4*W80.4*H77.56mm,fireproofing ABS,
T=3.0mm
,
black
,
texture MT11020
,
ROHS
,
REACH
2
27.4.042.0106 Front up corner
cap
IPA77/L40*W40*H40mm,TPU，T=4.5mm,black,TPU
Shore 90 degree,texture MT11020 and MT11000，tooling
No:2
，
ROHS,REACH
2
27.4.042.0107 Front bottom
corner cap
IPA77/L40*W40*H40mm,TPU, T=4.5mm,black,TPU Shore
90 degree,texture MT11020 and MT11000，tooling No:3,
ROHS
,
REACH
2
27.4.042.0108 Rear corner cap IPA77/L40*W40*H40mm,TPU, T=4.5mm,black,TPU Shore
90 degree,texture MT11020 and MT11000, tooling
No:1
,
ROHS
,
REACH
4
17.5.099.0004 FM antenna
￠5.8*110*30mm,ROHS,REACH
1
17.5.007.0246 Metal grille IPA77/L268.5*W240.95*H4.4mm,SPCC, T=1.2mm,hole
size φ3.0*P4.0*T1.2mm, salty test 48H,ROHS,REACH
1
17.5.005.0024 Real metal panel
IPA77/L135xW90xH1.5mm,SPCC，T=1.5mm,salty test
48H,，silkscreen:ION TAILGATER IPA77 POWER ON
OFF FUSE INPUT RANGE 100-240V 50/60Hz 50W
etc.Pantone Cool Grey 6C,ROHS,REACH
1
Screws
(RoHS，Reach)
78

ION Tailgater iPA77 Specifications

General

RMS rated power	50 W
Product color	Black
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	70 mm
Width	90 mm
Height	101 mm
Weight	7400 g
