iOptron CEM70 Quick Start Guide

If you connect the mount to a PC via the USB
port on the RA axle, you should see iPolar under
Camera of PC Device Manager. If a FTDI VCP
drive is installed, you should also see an
assigned COM port under the Port of the Device
Manager.
iPolar
USB

iOptron CEM70 Specifications

General

Azimuth Adjustment	±10°
Level Indicator	Yes
Database	212, 000+ objects
Payload Capacity	70 lbs (31.8 kg)
Slew Speed	6.5°/sec
Counterweight Shaft	28mm diameter
Polar Scope	Built-in, illuminated
Go2Nova® Hand Controller	Yes
GPS	Built-in
Communication Ports	USB, RS-232, ST-4
Power Supply	12V DC
Dovetail Saddle	Losmandy/Vixen dual saddle
PEC	Permanent PEC
Guiding	ST-4
Tripod	Optional
Tracking Accuracy	≤ ±5 arcsec
