iOptron SkyTracker User Manual

13
Appendix A. Technical Specifications
Mount Ultra compact EQ
Payload (MAX) 7.7 lbs (3.5kg)
Mount weight 2.6 lbs (1.2kg) w/o battery
Body material Cast aluminum
Latitude adjustment range 0º ~ 70º
Worm wheel Φ80mm, 156 teeth aluminum alloy
Worm gear Φ11mm, brass
Bearing 4 pieces
Motor drive DC servo
Tracking R.A. automatic
Tracking speed 1X Cel, 1/2 Cel, N/S
Polar sight hole ~ 8.5º FOV
Polar scope 6º FOV with dark field illuminated (optional for #3303)
Power consumption DC 4.8 ~ 6V, 0.06A at Max load
Power requirement 4 AA batteries, or External DC 9 ~12V, 500mA
Duration of operation 24 hours at 20ºC
Built in accessory Latitude and azimuth adjustor, Compass
Dimensions 153 x 104 x 58 mm
Operation Temperature -10~40ºC
Base connect 3/8” threaded socket
Warranty One year limited

iOptron SkyTracker Specifications

General

Mount	Ultra compact EQ
Body material	Cast aluminum
Worm wheel	Φ80mm, 156 teeth aluminum alloy
Worm gear	Φ11mm, brass
Bearing	4 pieces
Motor drive	DC servo
Payload (MAX)	6.6 lbs (3kg)
Tracking	R.A. automatic
Tracking speed	1X Cel, 1/2 Cel, N/S
Duration of operation	24 hours at 20ºC
Latitude adjustment range	0º ~ 70º
Operation Temperature	-10~40ºC
Polar sight hole	~ 8.5º FOV
Polar scope	6º FOV with dark field illuminated (optional for #3301)
Built in accessory	Compass
Warranty	One year limited
Power consumption	DC 4.8 ~ 6V, 0.06A at Max load
Power requirement	4 AA batteries, or External DC 9 ~12V, 500mA
Base connect	3/8” threaded socket

Weight and Dimensions

Mount weight	2.4 lbs (1.1kg) w/o battery
Dimensions	153 x 104 x 58 mm
