114062B System Users Manual
C H A P T E R 6
SPECIFICATIONS
Voltage 120 or 277Vac 1-phase 2-wire +10% -20%. Contact factory for all other voltages.
Input Power Walk-in Walk-in limiting inrush current to less than 125%, 10 times for 1 line cycle
Input Frequency 60Hz, +/- 3%, 50Hz Available upon request
Synchronizing Slew Rate 1Hz per second nominal
Protection Input Circuit Breaker
Harmonic Distortion < 10%
120 or 277Vac 1-phase 2-wire. Contact factory for all other voltages.
Static Voltage Load current change +/-2%, battery discharge +/-12.5%
Dynamic Voltage +/- 2% for +/-25% load step change, +/-3% for a 50% load step change, recovery within 3 cycles
Harmonic Distortion < 3% THD for linear load
Output Frequency 60Hz +/- .05Hz during emergency mode
Load Power Factor .5 lag to .5 lead
Inverter Overload 115% for 10 minutes
Protection Optional Distribution Circuit Breakers
Battery
Type Valve-regulated sealed lead-calcium. Contact factory for additional battery types.
Microprocessor controlled for various battery types and temperature compensating (recharge per UL924 spec)
Protection Automatic low-battery disconnect; automatic restart upon utility return.
Optional Runtimes Extended runtimes available. Consult factory for additional information.
Environmental
Altitude < 10,000 feet (above sea level) without derating
Operating Temperature 20 to 30 degree Celsius
Storage Temperature -20 to 70 degrees Celsius (electronics only)
Relative Humidity < 95% (non-condensing)
General
Design Line interactive PWM inverter type utilizing IGBT technology with 2mS transfer time.
Generator Input Compatible with generators.
Control Panel Microprocessor controlled 4 x 20-charactor vacuum fluorescent display with touch pad controls/functions &
Metering Input & Output Voltage, Battery Voltage, Battery & Output Current, Output VA, Temperature, Inverter Wattage
Alarms High/Low Battery Charger Fault, Near Low Battery, Low Battery, Load Reduction Fault, Output Overload,
High/Low AC Input Volts, High Ambient Temperature, Inverter Fault, Output Fault, Optional Circuit Breaker Trip
RS-232 port (DB9). Optional E-mail/fax modem.
Manual Maintenance Bypass Optional Internal or optional external without internal distribution breakers.
Alarm Contacts Optional Summary Form "C" Contacts
Warranty 1 year standard warranty includes all parts, labor, & travel expenses within 48 contiguous states. Up to 10 years
prorated warranty on batteries. Extended warranties, preventative maintenance and customized service plans
Factory Start-up Purchase factory start-up & receive 1 additional year of warranty.
5 Year Service Plan Purchase 5 year service plan & receive free factory start-up.
Physical
Cabinet Freestanding NEMA Type 1
Cooling Forced Air, during emergency mode.
