114062B System Users Manual
Low VAC, High VAC, Near Low Battery, Low Battery, High Temperature
Parameters are set in Volts AC, Volts DC, and Degrees Centigrade respectively.
Use the left or right arrow key to turn on or off this alarm. When the alarm is turned
on, a number will appear. To change the number, press the ENTER key and then
use the left or right arrow key. Once the desired number is reached, press the
ENTER key and this will return to the top-level menu.
Table 5.3 Near Low Battery Fault Chart
DC Voltage Near Low Battery
Load Reduction Current
Parameters are set in Amps AC.
Use the same technique as the above alarms for modification.
Load Reduction Current is a useful diagnostic tool that will automatically generate a
fault when the output current is 10 percent higher or lower than the set-point number.
Status
Indicates the Status of the machine – Line Present, Battery Charging, Ready, Battery
Power, and if any faults are present.
System Information
Indicates Model Number, Serial Number and Current Software Revision Level of the
system.
Test Mode
To initiate a Test and cause the inverter to run on battery power.
