#9003A Mini MUTT
®
(For 7 Spade Pin)
Quickly Troubleshoot
and Repair Light-Duty
Trailer Lights (RV Style)
MUTT
®
PRODUCTS
#9008-SE Super MUTT
®
Base Model: 3-Button Remote Control, 5' 7-Way Cable,
Chassis Ground Cable, External Battery Connector, 8' Glad Hands
#9004A Smart MUTT
®
(For 7 Spade Pin
with Remote)
A Portable Unit for the
Light-Duty Trailer
Professional Service
Shop (RV Style)
#9007A Smart MUTT
®
(For 7 Round Pin
with Remote)
A Portable Unit for
the Mobile and
Commercial Trailer
Repair Shops
#9005A Super MUTT
®
Service Truck Edition
(For 7 Round Pin with
Remote)
Diagnostic Light,
Air Brake and ABS
Tester for Emergency
Vehicles (7 Round Pin)
#9008-UPKIT (This Kit Updates the #9008-SE to the #9008-DL): 2 Extra Remotes,
10A Battery Charger, Face Shield, Rain Cover, Shoulder Screws
#9101 Light Ranger MUTT
®
(For 7 Spade, 6 Round, and 4/5 Flat Pin)
Utility and RV Type Trailer Tester For Lights and
Electric Brakes
#9008-DL SUPER MUTT
®
Pro Edition:
12-Button Remote Control, (2) 3-Button Remote Controls,
5' 7-Way Cable, Chassis Ground Cable, External Battery
Connector, 8' Glad Hands, 10A Battery Charger,
Face/Battery Shield and Rain Cover
BATTERY NOT
INCLUDED
3
#9102 HEAVY RANGER MUTT
®
PARTS
USE THE REFERENCE NUMBERS PROVIDED
WHEN ORDERING PRODUCTS AND PARTS ABOVE
Toll Free: 888-786-7899
Fig. 1 - Parts Diagram
IMPORTANT SAFETY INSTRUCTIONS
IT IS IMPORTANT TO READ, UNDERSTAND AND FOLLOW ALL SAFETY MESSAGES
AND INSTRUCTIONS PRINTED IN THIS MANUAL AND ON THE EQUIPMENT BE-
FORE OPERATING. IF SAFETY INFORMATION IS NOT HEEDED, SERIOUS INJURY
OR DEATH TO THE OPERATOR OR BYSTANDERS MAY OCCUR.
DANGER: Indicates a hazardous situation that if not avoided, will result in death or serious
injury. The possible hazards are shown in the adjoining symbols or explained in the text.
WARNING: Indicates a hazardous situation that if not avoided, could result in death or seri-
ous injury. The possible hazards are shown in the adjoining symbols or explained in the text.
CAUTION: Indicates a hazardous situation that if not avoided, may result in minor or major
injury. The possible hazards are shown in the adjoining symbols or explained in the text.
Rubber Gasket
Lid Lock
Switch Plate
Control Knob
Enclosure
Battery Compartment
7 Round Socket
500mA Battery Charger
#CHR0001
12V Cigarette Socket
Rotary Switch
Padlock Hole
Illuminated Power Switch
Battery Leads
To Next Page
