IPC Gansow CT45 BT - Ct30 Technical Specifications

GB
CT30 TECHNICAL SPECIFICATIONS
CT30 B CT30 ECS CT30 C
Cleaning width mm 455
Squeegee width mm 545
Cleaning capacity per hour m
2
/h 1670
Number of brushes n° 1
Brush diameter mm 455
Maximum brush pressure g/cm
2
/
Brush rotation speed g/1° 140 600 140
Brush motor power W 350 350 400
Drive motor power W /
Maximum speed Km/h /
Suction motor power W 550 200 400
Solution tank L 28
Dirty water tank L 30
Rear wheel diameter mm 250
Maximum slope % /
Gross weight Kg 126 126 81
Transported weight Kg 76 76 28
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 74 /
Power system voltage V 24
Machine dimensions mm
X=850
Z=1220
Z1=745
Y=568
Battery compartment dimensions
(length, width, height)
mm 240x330x220 /
Packed size (length, width, height) mm 900x610x960
Sound pressure
LpA
(dB)
69 / 79,6
Measurement uncertainty
K
(dB)
///
Vibration level (hand)
HAV
m/sec2
1/1,1
Measurement uncertainty, k m/sec2 0,5 / 0,5
