IPC 121286 - Page 258

Table: ELEC. DIAGRAM 4 Progressive Number: 1
Date: 19/01/2017 Selected Part: MSUB00418 Page: 12
Ref. K Part N. Customer Part N. Description Qty
Validity:
From To Price
0HA1 MEVR33430 KLAXON K100/Y 1A 24V 1,00 --
0KA1 MERL00015 SWITCH RELAY 24V 1,00 --
0KA2 MERL00015 SWITCH RELAY 24V 1,00 --
0KA3 MERL00015 SWITCH RELAY 24V 1,00 --
0KA4 MERL00015 SWITCH RELAY 24V 1,00 --
0KA5 MERL00016 SWITCH RELAY 24V 1,00 --
0KA6 MERL00016 SWITCH RELAY 24V 1,00 --
0KA7 MERL00015 SWITCH RELAY 24V 1,00 --
0KA8 MERL00015 SWITCH RELAY 24V 1,00 --
0KM1 METT00079 CONTACTOR E TL 10P 24V 100A 1,00 --
0MD1 VEVR00070 IMPELLER - 1,00 --
0MD2 MOCC00372 MOTOR - 1,00 --
0MD3 RDGR31335 MOTOR.GEARBOX L. 70TE 1,00 --
KA10 METT00084 CONTACTOR 180A 1,00 --
KA11 METT00083 CONTACTOR 280A 1,00 --
KA12 MERL00015 SWITCH RELAY 24V 1,00 --
