2.3. Documentation provided with the machine
• user manual;
• guarantee certificate;
• EC certificate of conformity.
3. TECHNICAL INFORMATION
3.1. General description
This machine is a motorised sweeper designed to sweep floors in civil and industrial
premises.
The motorised sweeper may be used to clean the residues from industrial processes,
dust and dirt in general on all relatively even flat hard surfaces such as concrete, asphalt,
porcelain stoneware, ceramic tiles, sheet metal, marble, embossed or smooth rubber or
plastic mats indoors or outdoors.
3.2. Legend
The main parts of the machine are as follows (fig. A-B):
• Debris bin (fig. B, ref. 1), contains the material picked up by the centre brush and the
dust from the filter
• Control panel (fig. C )
• Centre brush (fig. F-G), the principal organ of the machine, transfers the dust and
debris to the bin. Available with bristles of different hardnesses and materials according
to the type of debris to be picked up.
• Side brushes (fig. A, ref. 1), convey the dust and debris, used exclusively to clean
edges, corners and profiles.
• Suction filter (fig. L ), consists of a polyester bag filter which filters the air drawn in by
the suction fan.
• Suction fan, enables the machine to sweep without raising dust (fig. B, ref. 2).
• Flaps (fig. O-P-Q ), surround the centre brush and guarantee the suction effect.
3.3. Danger zones
• Control panel: danger of short circuit.
• Centre brush: danger due to brush rotation.
• Side brushes: danger due to brush rotation.
• Back/front wheels: danger of crushing between the wheel and chassis.
• Motor/battery compartment: danger of short circuit between the battery poles, risk of
serious burns when performing any maintenance with the engine off but not completely
cold (PETROL and DIESEL version).
• Debris bin: during bin raising/lowering, danger of crushing.
4. SAFETY INFORMATION
4.1. Safety regulations
Read the "User Manual" carefully before start-up and use or before performing
maintenance or any other work on the machine.
