(g. 22, ref. 1) main fuse.
(g. 23, ref. 1-2) brush motor fuses.
(g. 23, ref. 3) head actuator, squeegee actuator fuse.
(g. 23, ref. 4) suction motor fuse.
(g. 23, ref. 5) solenoid valve, Chem-Dose pump fuse.
1 2
3 4
5 1 2 4
5
3
To serial number :
80000262687
From serial number:
80000262688
23
1
22
