ENGLISH - 3
1.1 INTRODUCTION
DANGER:
Before using the appliance, read the accom-
panying “SINGLE DISC SAFETY WARN-
INGS” booklet carefully.
This manual forms an integral part of the ma
-
chine itself. It must therefore be kept in a safe
place where it is accessible to all users (opera
-
tors and maintenance personnel) throughout
the life of the machine until it is scrapped.
1.2 - INTENDED USE OF
THE MACHINE
The machine has been designed and built:
for cleaning floors and carpets, for polishing
floors, for sanding floors (e.g. parquet and
uneven surfaces).
DANGER:
Any other use releases the manufacturer
from liability for harm to persons and/or
property and invalidates any warranty
condition.
1.3 - NON-INTENDED USE
OF THE MACHINE
WARNING:
The machine is not intended for outdoor
use.
DANGER:
- do not wash floors with water above 50 °C;
- do not use diesel/petrol or corrosive de-
tergents to wash floors;
- do not wash and suck up corrosive, flam-
mable or explosive liquids, even if diluted.
2.1 COMPONENT
ASSEMBLY
2.1.a - Positioning the handle (Fig. 1)
For models with 4-screw handle fixing:
- Place the handle (1) on the base (2),
aligning the four holes on the handle with
the holes on the machine body.
- Tighten the screws (3) provided.
For models with 2-nut handle fixing:
- Unscrew the two nuts (4) from the ma-
chine body (5).
- Position the handle (6) by inserting the
pins present on the machine body (5).
- Tighten the nuts (4).
2.1.b - Electrical machine handle/
body connection (Fig. 2)
- Plug the handle into the machine body
by putting the plug (7) into the machine
socket (8);
For models equipped with a socket with
gasket (9) put the gasket in place be-
fore connecting the plug and tighten the
screws (10) supplied.
2.1.c - Assembling the cable reel
supports (Figs. 3/5)
Some models are equipped with cable reel
supports that must be assembled directly on
the shaft of the handle:
- Fit the short coupling (11) into the long
coupling (12) (Fig. 3).
- Tighten the screw (13) to the knob (14),
keeping the latter to the right (Fig. 4).
- The hook (15) of the support can be ro-
tated depending on usage (Fig. 5).
- Place one support at the top of the handle
and a second support at the bottom.
